• High-Resolution Video: 2 MP (1920 × 1080) resolution for crisp and detailed imaging.
• Audio Capability: Built-in microphone with audio transmission over coaxial cable for enhanced safety and monitoring.
• Night Vision: EXIR 2.0 infrared technology with up to 25 m IR range for clear imaging in complete darkness.
• Wide Compatibility: 4-in-1 switchable signals (TVI/AHD/CVI/CVBS) for flexible integration.

• Weatherproof Design: IP67-rated for protection against water and dust.

Lens Options:

• 2.8 mm: Horizontal FOV: 106.4°, Vertical FOV: 57.9°, Diagonal FOV: 124.6°.
• 3.6 mm: Horizontal FOV: 79.6°, Vertical FOV: 43.5°, Diagonal FOV: 93.7°.
• 6 mm: Horizontal FOV: 51.9°, Vertical FOV: 30°, Diagonal FOV: 58.8°.
• Lens Mount: M12.

Imaging Performance:

• Min. Illumination: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR.

• Frame Rates:

  TVI, AHD, CVI: 1080p @ 25/30 fps.
  CVBS: PAL/NTSC.

• Day/Night Mode: Auto, Color, or Black & White (ICR).
• Wide Dynamic Range (WDR): Digital WDR for clear imaging in high-contrast lighting conditions.

Image Enhancements:

• Adjustable Parameters: Brightness, sharpness, and smart IR.
• Modes: Standard (STD) and High Saturation (HIGH-SAT).

Interface:

• Video Output: Switchable TVI/AHD/CVI/CVBS for compatibility with various systems.

Durability & Design:

• Material: Durable plastic housing.

• Operating Conditions:

  Temperature: -40 °C to 60 °C (-40 °F to 140 °F).
  Humidity: ≤90% (non-condensing).

• Dimensions: 58 mm × 61 mm × 158.6 mm (2.28" × 2.40" × 6.42").
• Weight: Approx. 160 g (0.35 lb).

Power Requirements:

• Power Supply: 12 VDC ± 25%.
• Power Consumption: Max. 2.7 W.

Certifications:

• Protection: IP67-rated for reliable performance in outdoor and indoor environments.
