- Full-Color Imaging: 24/7 color monitoring with advanced 5 MP CMOS sensor.
- Enhanced Lighting: Warm supplemental light with up to 20 m range.
- Clear Imaging: 130 dB true WDR for backlight compensation and 3D DNR for sharp, noise-free visuals.
- Flexible Signal Options: Switchable 4-in-1 video output (TVI/AHD/CVI/CVBS).
-
Rugged Build: IP67-rated for water and dust resistance.
Camera Details:
- Image Sensor: 5 MP CMOS
-
Max. Resolution: 2560 (H) × 1944 (V)
-
Min. Illumination:
0.0005 Lux @ (F1.0, AGC ON)
0 Lux with white light -
Shutter Time:
PAL: 1/25 s to 1/50,000 s
NTSC: 1/30 s to 1/50,000 s -
Day/Night Mode: Full color
Lens Options:
- Lens Type: 3.6 mm and 6 mm fixed lens
- Field of View:
-
3.6 mm: Horizontal 80.1°, Vertical 49.3°
6 mm: Horizontal 49.3°, Vertical 28°
Image Features:
-
Frame Rate:
TVI: 5 MP@20fps, 4 MP@25/30fps, 1080p@25/30fps
CVI: 4 MP@25/30fps
AHD: 5 MP@20fps, 4 MP@25/30fps - WDR: True WDR (≥130 dB)
- Image Enhancements: Brightness, sharpness, mirror, smart light, BLC, HLC.
-
White Light Alarm: Automatic or manual.
-
Material:
Front Cover: Metal
Main Body: Plastic - Power Supply: 12 VDC ± 25%
- Consumption: Max. 3.5 W
- Operating Conditions: -40°C to 60°C (-40°F to 140°F), ≤ 90% humidity (non-condensing).
- Dimensions: Φ109.82 mm × 85.56 mm (4.32" × 3.37").
-
Weight: Approx. 350 g (0.77 lb.).
Interface:
- Video Output: Switchable TVI/AHD/CVI/CVBS.
- Communication: HIKVISION-C protocol.
