- High-Quality Audio: Coaxial audio camera with a built-in microphone for clear sound transmission.
- Advanced IR Technology: EXIR 2.0 with 20 m infrared range for superior night vision.
- Versatile Video Output: 4-in-1 switchable signals (TVI/AHD/CVI/CVBS).
- Compact Design: Ideal for indoor surveillance, providing both audio and video in one camera.
Camera Details:
- Image Sensor: 2 MP CMOS
- Max. Resolution: 1920 (H) × 1080 (V)
-
Min. Illumination:
0.01 Lux @ (F2.0, AGC ON)
0 Lux with IR - Shutter Time:
PAL: 1/25 s to 1/50,000 s
NTSC: 1/30 s to 1/50,000 s
-
Day/Night Mode: ICR (infrared cut filter)
Lens Options:
- Lens Type: 2.8 mm, 3.6 mm, 6 mm fixed lens
-
Field of View:
2.8 mm: Horizontal 106.4°, Vertical 57.9°
3.6 mm: Horizontal 79.6°, Vertical 43.5°
6 mm: Horizontal 51.9°, Vertical 30°
Frame Rate:
- TVI: 1080P@30fps, 1080P@25fps
- AHD: 1080P@30fps, 1080P@25fps
- CVI: 1080P@30fps, 1080P@25fps
- CVBS: PAL/NTSC
Wide Dynamic Range (WDR): Digital WDR
Audio Features:
- Microphone: Built-in microphone with audio transmission over coaxial cable
- Audio Quality: Clear audio for surveillance monitoring
General Features:
- Material: Plastic
- Power Supply: 12 VDC ± 25%
- Power Consumption: Max. 2.7 W
- IR Range: Up to 20 m
-
Operating Conditions:
Temperature: -40°C to 60°C (-40°F to 140°F)
Humidity: 90% or less (non-condensing) - Communication: HIKVISION-C protocol
- Dimensions: Φ 84.6 mm × 78.9 mm (Φ 3.33" × 3.11")
-
Weight: Approx. 140.5 g (0.31 lb.)
