- High Resolution: 5 MP (2560 × 1944) for detailed imaging.
- Wide Dynamic Range: Digital WDR ensures clear visuals in challenging lighting.
- Enhanced Night Vision: Smart IR provides up to 20 m IR distance.
- Built-in Audio: Integrated microphone transmits audio over coaxial cable for added security.
- Versatile Output: 4-in-1 video output (TVI/AHD/CVI/CVBS) for compatibility with various systems.
- Compact Design: Ideal for indoor applications with adjustable viewing angles.
Camera Details:
- Image Sensor: 5 MP CMOS
- Max. Resolution: 2560 (H) × 1944 (V)
-
Min. Illumination:
0.01 Lux @ (F2.0, AGC ON)
0 Lux with IR -
Shutter Time:
PAL: 1/25 s to 1/50,000 s
NTSC: 1/30 s to 1/50,000 s
-
Day/Night Mode: ICR (Infrared Cut Filter)
Lens Options:
- Lens Type: 2.8 mm, 3.6 mm, 6 mm fixed lens
-
Field of View:
2.8 mm: Horizontal 85.5°, Vertical 63.7°, Diagonal 110.7°
3.6 mm: Horizontal 80.1°, Vertical 63.7°, Diagonal 105.9°
6 mm: Horizontal 57.1°, Vertical 43.1°, Diagonal 72.5°
Frame Rate:
- TVI/AHD: 5MP@20fps, 4MP@30fps/25fps, 1080P@30fps/25fps
- CVI: 4MP@30fps/25fps
-
CVBS: PAL/NTSC
Image Enhancements:
- WDR: Digital WDR
- Noise Reduction: 2D DNR
-
Settings: Brightness, Sharpness, Mirror, Smart IR
General Features:
- Material: Plastic
- Dimensions: Φ 84.6 mm × 78.9 mm (Φ 3.33" × 3.11")
- Weight: Approx. 140.5 g (0.31 lb.)
- Power Supply: 12 VDC ± 25%
- Power Consumption: Max. 3.7 W
-
Operating Conditions:
Temperature: -40 °C to 60 °C (-40 °F to 140 °F)
Humidity: 90% or less (non-condensing)
- IR Range: Up to 20 m
- Communication Protocol: HIKVISION-C
