• High-Resolution Video: 2 MP (1920 × 1080) resolution for clear and detailed imaging.
• 24/7 Full-Color Imaging: F1.0 aperture and advanced white light illuminator for vivid color images, even at night.
• Night Vision: Up to 40 m white light range ensures bright and clear night surveillance.
• Wide Dynamic Range (WDR): 130 dB true WDR for enhanced image clarity in backlit conditions.
• Audio Integration: Built-in microphone for high-quality audio via coaxial cable.
• Flexible Signal Options: 4-in-1 switchable signals (TVI/AHD/CVI/CVBS) for compatibility.

• Weatherproof: IP67-rated for protection against dust and water.

Lens Options:

• 2.8 mm: Horizontal FOV: 98°, Vertical FOV: 52°, Diagonal FOV: 116°.
• 3.6 mm: Horizontal FOV: 77°, Vertical FOV: 42°, Diagonal FOV: 91°.
• 6 mm: Horizontal FOV: 51°, Vertical FOV: 28°, Diagonal FOV: 59°.
• Lens Mount: M12.

Imaging Performance:

• Min. Illumination: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light.
• Frame Rates:

  TVI, AHD, CVI: 1080p @ 25/30 fps.

  CVBS: PAL/NTSC.
• Noise Reduction: 3D/2D DNR for sharp and clean images.
• Day/Night Mode: Color imaging.

Image Enhancements:

• Adjustable Parameters: Brightness, contrast, sharpness, anti-banding, mirror, and AGC.
• Image Modes: Standard, High Saturation, and Highlight.

• Features: BLC, HLC, Global Highlight Suppression.

Interface & Events:

• Video Output: Switchable TVI/AHD/CVI/CVBS.
• Alarm: Solid white light for visual alerts.

• Motion Detection: 4 programmable motion detection areas.

Durability & Design:

• Material: Durable metal housing.
• Operating Conditions:

  Temperature: -40 °C to 50 °C (-40 °F to 122 °F).

  Humidity: ≤90% (non-condensing).
• Dimensions: 194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93").
• Weight: Approx. 515 g (1.13 lb).

Power Requirements:

• Power Supply: 12 VDC ± 25%.
• Power Consumption: Max. 5.7 W.

Certifications:

• Protection: IP67-rated for reliable outdoor performance.
