- High-Resolution Imaging: 5 MP (2560 × 1944) CMOS sensor for sharp visuals.
- PIR Detection & Alarm: PIR motion detection with strobe light alarm and alarm out to deter intruders in real-time.
- Enhanced Night Vision: EXIR 2.0 infrared technology with a 20 m IR range for clear images in darkness.
- Rugged Design: Water and dust resistance with IP67 rating for durability.
- Image Sensor: 5 MP CMOS
- Max. Resolution: 2560 (H) × 1944 (V)
-
Min. Illumination:
0.01 Lux @ (F2.0, AGC ON)
0 Lux with IR -
Shutter Time:
PAL: 1/20 s to 1/50,000 s
NTSC: 1/20 s to 1/50,000 s -
Day/Night Mode: ICR (Infrared Cut Filter)
Lens Options: Lens Type: 2.8 mm or 3.6 mm fixed lens -
Field of View:
2.8 mm: Horizontal 85.5°, Vertical 63.8°, Diagonal 110.7°
3.6 mm: Horizontal 80.1°, Vertical 63.8°, Diagonal 105.9°
Image Features:
- Frame Rate: TVI: 5 MP@20fps, 4 MP@25/30fps, 1080P@25/30fps
- WDR: Digital WDR for better image clarity.
- Image Enhancements: Brightness, sharpness, DNR, mirror, and smart IR.
-
White Light Alarm: Auto/off functionality for added security.
General Features:
-
Material:
Enclosure: Plastic
Main Body: Metal
Power Supply: 12 VDC ± 25% - Consumption: Max. 3.5 W
- Operating Conditions: -40°C to 60°C (-40°F to 140°F), ≤ 90% humidity (non-condensing).
- Dimensions: Φ109.8 mm × 89.75 mm (Φ4.32" × 3.53").
- Weight: Approx. 327 g (0.72 lb.).
- Video Output: 1 HD analog output (TVI).
- Communication: HIKVISION-C protocol.
