• High-Quality Imaging: 2 MP resolution (1920 × 1080) for clear and sharp video quality.
• Advanced Night Vision: Up to 30 m infrared (IR) distance for effective low-light performance, and up to 20 m white light for bright night imaging.
• Audio Functionality: Built-in microphone with audio over coaxial cable, offering high-quality audio surveillance.
• Flexible Lighting Options: Smart-Hybrid light optimizes security with adjustable lighting for day and night.
• Durable and Weatherproof: IP67-rated water and dust resistance for reliable performance in various environments.
• 4-in-1 Video Output: Switchable between TVI, AHD, CVI, and CVBS for versatile compatibility.

Specifications:

Camera Details:

• Image Sensor: 2 MP CMOS
• Max. Resolution: 1920 (H) × 1080 (V)

• Min. Illumination:

  0.01 Lux @ (F1.6, AGC ON)

  0 Lux with IR

• Shutter Time:

  PAL: 1/25 s to 1/50,000 s

  NTSC: 1/30 s to 1/50,000 s




• Day & Night Mode: ICR (infrared cut filter)

Lens Options:

• Lens Type: 2.8 mm, 3.6 mm fixed focal lens
• Field of View:

  2.8 mm: Horizontal 101°, Vertical 56°

  3.6 mm: Horizontal 78°, Vertical 42°

Audio Functionality:

• Microphone Pickup Distance: Up to 5 m

Frame Rate:

• TVI: 1080P @ 30 fps, 1080P @ 25 fps
• AHD: 1080P @ 30 fps, 1080P @ 25 fps
• CVI: 1080P @ 30 fps, 1080P @ 25 fps
• CVBS: PAL/NTSC

Wide Dynamic Range (WDR): Digital WDR

General Features:

• Material: Metal
• Dimensions: 80 mm × Ø85.1 mm (3.1" × Ø3.4")
• Weight: Approx. 296 g (0.65 lb.)
• Power Supply: 12 VDC ± 25%
• Power Consumption: Max. 3.3 W
• Operating Condition:

  Temperature: -40°C to 60°C (-40°F to 140°F)

  Humidity: 90% or less (non-condensing)
• Communication Protocol: HIKVISION-C
• Protection Rating: IP67
