• High-Resolution Imaging: 2 MP (1920 × 1080) resolution for clear, detailed video.
• Smart Hybrid Light: Flexible lighting options with IR (up to 30 m) and white light (up to 20 m).
• Audio Capability: Built-in microphone with up to a 5 m pickup radius, transmitting audio over coaxial cable for enhanced security.
• Wide Compatibility: 4-in-1 switchable signals (TVI/AHD/CVI/CVBS).

• Weatherproof Design: IP67-rated for reliable performance in various environments.

Lens Options:

• 2.8 mm: Horizontal FOV: 101°, Vertical FOV: 56°, Diagonal FOV: 118°.
• 3.6 mm: Horizontal FOV: 78°, Vertical FOV: 42°, Diagonal FOV: 92°.

• Lens Mount: M12.

Imaging Performance:

• Min. Illumination: 0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR.
• Frame Rates:

  TVI, AHD, CVI: 1080P @ 25/30 fps.

  CVBS: PAL/NTSC.
• Day/Night Modes: Auto/Color.
• Wide Dynamic Range (WDR): Digital WDR for balanced lighting in high-contrast scenes.

Image Enhancements:

• Adjustable Parameters: Brightness, sharpness, and smart IR.
• Image Optimization: DWDR, BLC, HLC, and Global.

Illumination:

• IR Distance: Up to 30 m.
• White Light Distance: Up to 20 m.

• Smart Illumination: Automatically adjusts lighting based on scene requirements.

Interface:

• Video Output: Switchable TVI/AHD/CVI/CVBS for flexible integration.

Durability & Design:

• Material: Durable metal housing.
• Operating Conditions:

  Temperature: -40 °C to 60 °C (-40 °F to 140 °F).

  Humidity: ≤90% (non-condensing).
• Dimensions: 138.8 mm × 60.9 mm × 57.9 mm (5.47" × 2.4" × 2.3").
• Weight: Approx. 266 g (0.59 lb).

Power Requirements:

• Power Supply: 12 VDC ± 25%.
• Power Consumption: Max. 3.3 W.

Certifications:

• Protection: IP67-rated for water and dust resistance.
