• 2 MP high-performance CMOS
• Resolution: 1920 × 1080
• Lens Options: 2.8 mm, 3.6 mm fixed lens
• IR Distance: Up to 20 m
• OSD Menu, DNR, DWDR
• Analog HD Output
• Up the coax (HIKVISION-C)

Camera Specifications:

• Image Sensor: 2 MP CMOS
• Signal System: PAL/NTSC
• Frame Rate:
  PAL: 1080p@25fps
  NTSC: 1080p@30fps

• Resolution: 1920 (H) × 1080 (V)
• Min. Illumination: 0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Time:
  PAL: 1/25 s to 1/50,000 s
  NTSC: 1/30 s to 1/50,000 s

• Lens: 2.8 mm, 3.6 mm fixed lens
• Horizontal Field of View: 103° (2.8 mm), 82.2° (3.6 mm)
• Lens Mount: M12
• Day & Night: IR cut filter

• Angle Adjustment:
  Pan: 0° to 360°
  Tilt: 0° to 75°
  Rotation: 0° to 360°

• Synchronization: Internal synchronization
• WDR (Wide Dynamic Range): DWDR
• Menu: Image Mode (STD/HIGH-SAT), AGC support, Day/Night Mode (Smart/Color/BW), Backlight Compensation, DWDR support
• Functions: Brightness, Sharpness, DNR, Mirror

• Video Output: 1 HD analog output

General Specifications:

• Operating Conditions: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing)
• Power Supply: 12 VDC ±15%
• Power Consumption: Max. 4 W
• Material: Plastic
• IR Range: Up to 20 m
• Dimensions: Ø 89.9 mm × 71.3 mm (Ø 3.54" × 2.81")

• Weight: Approx. 120 g (0.26 lb.)
