- High-Resolution Imaging: 3K resolution (2960 × 1665) for crystal-clear video quality.
- 24/7 Color Imaging: F1.0 aperture ensures vibrant color footage even in low-light conditions.
- Flexible Lens Options: Available in 2.8 mm and 3.6 mm fixed focal lenses for varying fields of view.
- Advanced Night Vision: White light illuminator with a range of up to 20 m for bright and detailed night surveillance.
- Audio Capability: Built-in microphone supports high-quality audio over coaxial cable.
- Signal Compatibility: 4-in-1 port supporting TVI/AHD/CVI/CVBS video signals.
-
Weatherproof: IP67-rated for water and dust resistance.
Lens Specifications:
- 2.8 mm Lens: Horizontal FOV: 102°, Vertical FOV: 56°, Diagonal FOV: 122°.
- 3.6 mm Lens: Horizontal FOV: 80°, Vertical FOV: 45°, Diagonal FOV: 96°.
-
Lens Mount: M12.
Imaging Performance:
- Min. Illumination: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light.
-
Frame Rates:
TVI: 3K @ 20 fps, 4 MP @ 25/30 fps, 1080p @ 25/30 fps.
AHD: 5 MP @ 20 fps, 4 MP @ 25/30 fps.
CVI: 4 MP @ 25/30 fps.
CVBS: PAL/NTSC.
-
WDR Technology: Digital WDR for enhanced image clarity in high-contrast lighting.
Image Enhancements:
- Day/Night Mode: Full color.
- Adjustable Parameters: Brightness, contrast, sharpness, mirror, defective pixel correction, AGC, and smart light.
- Noise Reduction: 2D DNR.
- Wide Dynamic Range (WDR), BLC, HLC, and Global Highlight Suppression.
Interface & Alarm Features:
- Video Output: Switchable TVI/AHD/CVI/CVBS.
- Alarm: Solid white light alarm for visual alerts.
Durability & Design:
- Material: Lightweight plastic.
-
Operating Conditions:
Temperature: -40°C to 60°C (-40°F to 140°F).
Humidity: ≤90% (non-condensing).
- Dimensions: 161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76").
- Weight: Approx. 238 g (0.52 lb).
Power Requirements:
- Power Supply: 12 VDC ± 25%.
- Power Consumption: Max. 2.5 W.
Certifications:
-
Protection: IP67-rated for reliable performance in outdoor and harsh environments.
