• Image Sensor: 2 MP CMOS Image Sensor
• Signal System: PAL/NTSC
• Effective Pixels: 1920 (H) x 1080 (V)
• Resolution: 1080p
• Min. Illumination: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
• Shutter Time: PAL: 1/25 (1/30) s to 1/50,000 s
• Lens Options:

3.6 mm (Standard), 6 mm, 8 mm, 12 mm, 16 mm optional
Field of View: 82.2° (3.6 mm), 54° (6 mm), 37.7° (8 mm), 24.2° (12 mm), 18.8° (16 mm)

• Lens Mount: M12
• Day & Night: ICR (Auto)
• Angle Adjustment:
  Pan: 0° to 360°
  Tilt: 0° to 180°
  Rotation: 0° to 360°


• Synchronization: Internal synchronization
• Video Frame Rate: 1080p @ 25fps/30fps
• HD Video Output: 1 analog HD output
• S/N Ratio: >62 dB
• IR Range: Up to 80 m
• IR Features: Smart IR
• Power Supply: 12 V DC ±15%
• Power Consumption: Max. 6 W
• Protection Level: IP66 (Weatherproof)
• Operating Conditions: -40 °C to 60 °C (-40 °F to 140 °F), Humidity 90% or less (non-condensing)
• Dimensions: 86.7 mm x 81.6 mm x 226 mm (3.4" x 3.2" x 8.9")
• Weight: 430 g (0.95 lb)
