• 5 MP high-performance CMOS
• Resolution: 2560 × 1944
• Lens Options: 2.8 mm, 3.6 mm, 6 mm fixed lens
• EXIR 2.0, smart IR, up to 20 m IR distance
• OSD menu, 2D DNR, DWDR
• 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
• IP67 protection

• Up the coax (HIKVISION-C)

Camera Specifications:

• Image Sensor: 5 MP CMOS
• Resolution: 2560 (H) × 1944 (V)
• Min. Illumination: Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Time:

  PAL: 1/25 s to 1/50,000 s

  NTSC: 1/30 s to 1/50,000 s

• Lens: 2.8 mm, 3.6 mm, 6 mm fixed lens

• Horizontal Field of View: 85.5° (2.8 mm), 80.1° (3.6 mm), 57.1° (6 mm)

• Lens Mount: M12
• Day & Night: IR cut filter

• Angle Adjustment:

  Pan: 0° to 360°

  Tilt: 0° to 180°

  Rotation: 0° to 360°

• Synchronization: Internal synchronization
• Frame Rate:

  PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps

  NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps
• Menu: AGC, D/N Mode (Auto/Color/BW), White Balance (ATW/MWB), BLC, DWDR, Brightness, Sharpness, DNR, Mirror, Smart IR
• Video Output: 1 HD analog output

• Switch Button: TVI/AHD/CVI/CVBS

General Specifications:

• Operating Conditions: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing)
• Power Supply: 12 VDC ±25%
• Power Consumption: Max. 4.3 W
• Protection Level: IP67
• Material: Plastic
• IR Range: Up to 20 m
• Communication: Up the coax, Protocol: HIKVISION-C (TVI output)
• Dimensions: 58 mm × 61 mm × 163 mm (2.28" × 2.40" × 6.42")

• Weight: Approx. 350 g (0.77 lb.)
