- High-Quality Imaging: 2 MP resolution (1920 × 1080) delivers clear and detailed video.
- Night Vision: Up to 20 m infrared (IR) distance and 20 m white light range for optimal night surveillance.
- Smart-Hybrid Light: Flexible lighting options with Smart, IR, and White Light modes for improved security.
- Audio Surveillance: Built-in microphone transmits high-quality audio over coaxial cable.
-
Versatile Compatibility: Switchable video output (TVI/AHD/CVI/CVBS) for compatibility with various systems.
Camera Details:
- Image Sensor: 2 MP CMOS
- Max. Resolution: 1920 (H) × 1080 (V)
-
Min. Illumination:
0.01 Lux @ (F1.6, AGC ON)
0 Lux with IR - Shutter Time:
PAL: 1/25 s to 1/50,000 s
NTSC: 1/30 s to 1/50,000 s
-
Day & Night Mode: ICR (Infrared Cut Filter)
Lens Options:
- Lens Type: 2.8 mm, 3.6 mm fixed focal lens
-
Field of View:
2.8 mm: Horizontal 101°, Vertical 56°, Diagonal 118°
3.6 mm: Horizontal 78°, Vertical 42°, Diagonal 92°
Audio Functionality:
-
Microphone Pickup Distance: Up to 5 m
Frame Rate:
- TVI/AHD/CVI: 1080P @ 30 fps / 25 fps
- CVBS: PAL/NTSC
Wide Dynamic Range (WDR): Digital WDR
General Features:
- Material: Plastic
- Dimensions: 84.6 mm × Ø85.02 mm (3.33" × Ø3.35")
- Weight: Approx. 156 g (0.34 lb.)
- Power Supply: 12 VDC ± 25%
- Power Consumption: Max. 3.3 W
-
Operating Conditions:
Temperature: -40 °C to 60 °C (-40 °F to 140 °F)
Humidity: 90% or less (non-condensing)
- Communication Protocol: HIKVISION-C
- Protection Rating: IP67
