• High Resolution: 5 MP (2560 × 1944) for crisp and clear video.
• Wide Dynamic Range (WDR): Digital WDR ensures clear imaging in varied lighting conditions.
• Enhanced Night Vision: Smart IR provides up to 30 m IR distance for superior night imaging.
• Audio Capabilities: Built-in microphone transmits high-quality audio over coaxial cable.
• Versatile Output: 4-in-1 video output (TVI/AHD/CVI/CVBS) for compatibility with multiple systems.
• Weather-Resistant: IP67-rated for durability against water and dust.

Camera Details:

• Image Sensor: 5 MP CMOS
• Resolution: 2560 (H) × 1944 (V)

• Min. Illumination:

  0.01 Lux @ (F2.0, AGC ON)

  0 Lux with IR

• Shutter Time:

  PAL: 1/25 s to 1/50,000 s

  NTSC: 1/30 s to 1/50,000 s

• Day/Night Mode: ICR (Infrared Cut Filter)

Lens Options:

• Lens Type: 2.8 mm, 3.6 mm, 6 mm fixed lens
• Field of View:

  2.8 mm: Horizontal 85.5°, Vertical 63.7°, Diagonal 110.7°

  3.6 mm: Horizontal 80.1°, Vertical 63.7°, Diagonal 105.9°

  6 mm: Horizontal 57.1°, Vertical 43.1°, Diagonal 72.5°

Frame Rate:

• TVI/AHD: 5MP@20fps, 4MP@30fps/25fps, 1080P@30fps/25fps
• CVI: 4MP@30fps/25fps

• CVBS: PAL/NTSC

Image Enhancements:

• WDR: Digital WDR
• Noise Reduction: 2D DNR

• Settings: Brightness, Sharpness, Mirror, Smart IR

General Features:

• Material: Metal
• Dimensions: 82.6 mm × 90 mm × 79.37 mm (3.25" × 3.54" × 3.12")
• Weight: Approx. 289.5 g (0.64 lb.)
• Power Supply: 12 VDC ± 25%
• Power Consumption: Max. 3.7 W
• Operating Conditions:

  Temperature: -40 °C to 60 °C (-40 °F to 140 °F)

  Humidity: 90% or less (non-condensing)
• Communication Protocol: HIKVISION-C
• IR Range: Up to 30 m

• Protection Rating: IP67
