• High-Resolution Imaging: 3K resolution (2960 × 1665) for crystal-clear video quality.
• Versatile Night Vision: Smart Hybrid Light offers up to 20 m IR and white light for enhanced night surveillance.
• Lens Options: Fixed focal lenses (2.8 mm and 3.6 mm) for varying field of view needs.
• Integrated Audio: Built-in mic with coaxial audio transmission for added security.
• Multi-Signal Compatibility: Switchable TVI/AHD/CVI/CVBS output for seamless integration.
• Compact and Durable: Lightweight plastic design, perfect for indoor use.

Camera Details:

• Image Sensor: 3K CMOS
• Max. Resolution: 2960 (H) × 1665 (V)

• Min. Illumination:
  0.01 Lux @ (F2.0, AGC ON)
  0 Lux with IR

• Shutter Time:
  PAL: 1/25 s to 1/50,000 s
  NTSC: 1/30 s to 1/50,000 s


• Day/Night Mode: ICR (Infrared Cut Filter)

Lens Options:

• Lens Type: 2.8 mm and 3.6 mm fixed lenses

• Field of View:

  2.8 mm: Horizontal 104.9°, Vertical 67.3°, Diagonal 129.8°
  3.6 mm: Horizontal 81.3°, Vertical 50.7°, Diagonal 102.4°

Lighting and Imaging:

• IR Range: Up to 20 m
• White Light Range: Up to 20 m
• WDR: Digital Wide Dynamic Range for better contrast in diverse lighting.
• Image Enhancements: DWDR, BLC, HLC, and Global settings.

General Features:

• Material: Plastic
• Dimensions: 84.6 mm × Ø85.02 mm (3.33" × Ø3.35")
• Weight: Approx. 160 g (0.35 lb.)
• Power Supply: 12 VDC ± 25%
• Power Consumption: Max. 2.9 W

• Operating Conditions:

  Temperature: -40 °C to 60 °C (-40 °F to 140 °F)
  Humidity: 90% or less (non-condensing)

• Communication Protocol: HIKVISION-C
