General Features:

• Standard Support: Gigabit Ethernet (1000 Base-T)

• Bandwidth: Up to 100 MHz

• Compliance:

• TIA/EIA-568.C.2

• ISO/IEC 11801

Construction & Material:

• Cable Type: 4-pair Unshielded Twisted Pair (UTP)

• Conductor: 24 AWG Solid Copper

• Insulation Material: HD-PE (High-Density Polyethylene)

• Jacket Material: FR PVC (Flame Retardant Polyvinyl Chloride)

• Jacket Hardness: 45P (90A ± 2A, Shore)

Shielding & Protection:

• Outside Tape Metal: MYLAR

• Overlap Rate: 25%

• Drain Wire: 24 AWG (0.500 ± 0.007mm)

Environmental & Heat Resistance:

• Heat Resistance: Minimum 75°C (Temperature Limited)

• Flammability Rating: UL94V-0
