• The D-Link Cat 6 Patch Cord 1M Yellow (NCB-C6UYELR1-1) is a high-quality Unshielded Twisted Pair (UTP) Ethernet cable designed for fast and reliable data transmission in Local Area Networks (LANs).

• It exceeds TIA/EIA-568C.2 and IEC 60603-7-4 standards, ensuring minimal interference, high durability, and superior signal integrity.

• Ideal for use in enterprise networks, data centers, and home networking setups, this patch cord supports 10/100/1000 Mbps and up to 10Gbps Ethernet connectivity.

Technical Specifications:

General Specifications:

• Brand: D-Link

• Model Number: NCB-C6UYELR1-1

• Category: Cat 6 UTP Patch Cord

• Color: Green

• Length: 1 Meter

Cable & Conductor Details:

• Conductor Material: Bare Copper

• Conductor Size: 24 AWG

• Shielding: Unshielded Twisted Pair (UTP)

• Structure: 4 Pairs Twisted Copper Wire

• Insulation Material: HD-PE (High-Density Polyethylene)

• Outer Jacket: PVC UL94V-0 (Flame Resistant)

• Heat Resistance: Minimum 60°C

Modular Connector / Plug Specifications:

• Connector Type: RJ-45 8P (Transparent Color)

• Gold Plating: 30U”

• Contact Blade Material: Phosphor Bronze

• Dielectric Withstanding Voltage: 500V AC

• Insulation Resistance: ≤ 35M Ohm

• Durability: 750 Matching Cycles

• Cable-to-Plug Tensile Strength: 20lbs (89N) Minimum

• Material: Polycarbonate (PC) UL94-V-0

Performance & Transmission:

• Ethernet Frequency: 550 MHz

• Data Transmission Speed: Up to 10Gbps

• Supported Network Protocols:

• 10BASE-T, 100BASE-TX, 1000BASE-T (IEEE 802.3)

• 100VG-AnyLAN (IEEE 802.12)

• 155/622 Mbps ATM

• Power over Ethernet (PoE)

Environmental Conditions:

• Operating Temperature Range: -10°C to +80°C

• Storage Temperature Range: 0°C to +50°C

Certifications & Compliance:

• TIA/EIA-568C.2 Standard Compliant

• UL 444 (Copper Conductor)

• UL 758 / Style 2835

• UL 1581 (Test Standard)

• ETL Verified

• RoHS Compliant

• CUL Listed
