• The D-Link Cat 6 Patch Cord 5M Grey (NCB-C6UGRYR1-5) is a high-performance Unshielded Twisted Pair (UTP) Ethernet cable designed for fast and reliable data transmission over Local Area Networks (LANs).

• Built with solid copper conductors, HDPE insulation, and a PVC protective jacket, this patch cord minimizes interference and ensures stable 1Gbps data transfer at 250 MHz frequency.

• It is ideal for high-speed networking applications, including 10BASE-T, 100BASE-TX, and Gigabit Ethernet (1000BASE-T/1000BASE-TX).

Technical Specifications:

General Specifications:

• Brand: D-Link

• Model Number: NCB-C6UGRYR1-5

• Category: Cat 6 UTP Patch Cord

• Color: Blue

• Cable Length: 5 Meters

• Weight: 250 gram

Cable & Conductor Details:

• Conductor Material: Solid Copper

• Conductor Size: 24 AWG

• Shielding: Unshielded Twisted Pair (UTP)

• Structure: 4 Pairs Twisted Copper Wire

• Insulation Material: HD-PE (High-Density Polyethylene)

• Outer Jacket Material: PVC UL94V-0 (Flame Resistant)

Performance & Transmission:

• Ethernet Frequency: 250 MHz

• Maximum Data Transfer Speed: 1 Gbps

• Supported Network Protocols:

• 10BASE-T Ethernet

• 100BASE-TX Fast Ethernet

• 1000BASE-T / 1000BASE-TX (Gigabit Ethernet)

Modular Connector / Plug Specifications:

• Connector Type: RJ-45 8P (Transparent Color)

• Gold Plating: 30U”

• Contact Blade Material: Phosphor Bronze

• Dielectric Withstanding Voltage: 500V AC

• Insulation Resistance: ≤ 35M Ohm

• Durability: 750 Matching Cycles

• Cable-to-Plug Tensile Strength: 20lbs (89N) Minimum

• Material: Polycarbonate (PC) UL94-V-0

Certifications & Compliance:

• UL 444 (for Copper Conductors)

• UL 758 Style 2835

• UL 1581 (Test Standard)

• Verified TIA/EIA-568C.2 Standard by ETL, CUL Listed, RoHS Compliant
