General Details:

• Brand: D-Link

• Type: LAN Cable

• Cable Type: Cat6, 1000 Mbps Speed

• UTP/STP: Unshielded Twisted Pair (UTP)

• Color: Grey

• Suitable For: RJ45 CAT6 LAN

• Cable Length: 305 meters

Connectors & Compatibility:

• Connector 1: USB Type A

• Connector 2: CAT6

• Compatible Devices: Computer

Material & Construction:

• Conductor: 0.57 mm Bare Copper, 23AWG x 4 pairs

• Cable Structure: Stranded Round

• Nominal Outer Diameter: 6.1 mm

• Jacket Material: PVC

• Jacket Hardness: 45P (90A ± 2A, Shore)

• Insulation: HDPE Insulation

• Other Insulation Features: Two insulated conductors twisted together

Performance & Transmission Features:

• Cable Frequency: 250 MHz

• Ethernet Transmission Standard: 1000Base-T

• Rating Temperature: 75°C

• Dielectric Strength: 0.75 kV/m

• Nominal Impedance: 100 ohms

• Propagation Delay Skew: 45 nS / 100M

• Voltage Rating: 72 V

Additional Features:

• Compliance:

• TIA/EIA 568C.2

• ISO/IEC 11801 Class E

• UL-listed

• ETL Verified

• Other Features:

• 4-pair Shielded Twisted Pair (STP) Cable

• Pairs are braided in aluminum foil with drain wire

• 56nF/m mutual capacitance

• Conductor resistance: 9.38 ohm

• PE Insulation & Central Cross

• Packaged in an easy-to-pull box for easier installation

• Exceeds ANSI/TIA-568C.2, ISO 11801 Class E requirements
