D-Link Cat6 Cable 305 Mtrs Box – Red (NCB-C6UREDR-305)
Product Description
The D-Link Cat6 Cable 305 Mtrs Box – Red is a high-performance structured cabling solution designed to deliver reliable Gigabit Ethernet connectivity for enterprise and commercial networks. Engineered to meet TIA/EIA 568C.2 and ISO/IEC 11801 Class E standards, this cable supports data transmission speeds up to 1000 Mbps (1 Gbps) with a frequency rating of 250 MHz.
Manufactured with high-quality 23 AWG bare copper conductors, the cable ensures superior signal integrity, reduced crosstalk, and stable network performance. The HDPE insulation and durable PVC jacket provide mechanical strength and long-term durability.
Supplied in a 305-meter easy pull box, it allows smooth installation and is ideal for LAN infrastructure, office networking, data centers, and structured cabling systems.
Key Highlights
✔ Category 6 UTP LAN Cable
✔ 305 Meter Pull Box
✔ Supports 1000Base-T (Gigabit Ethernet)
✔ 250 MHz Frequency
✔ 23 AWG Bare Copper Conductors
✔ TIA/EIA 568C.2 & ISO/IEC 11801 Class E Compliant
✔ ETL Verified & UL Listed
✔ Durable PVC Jacket – Red Color
Technical Specifications
General Specifications
- Brand: D-Link
- Model: NCB-C6UREDR-305
- Part Number: NCB-C6UREDR-305
- Cable Type: Cat6 LAN Cable
- Type: Unshielded Twisted Pair (UTP)
- Color: Red
- Cable Length: 305 Meters
- Ethernet Standard: 1000Base-T
- Cable Frequency: 250 MHz
- Suitable For: RJ45 CAT6 LAN Applications
- Compatible Devices: Computer, Switches, Routers, Patch Panels
Transmission Features
- Nominal Impedance: 100 Ohms
- Propagation Delay Skew: 45 ns / 100 m
- Dielectric Strength: 0.75 kV/m
- Voltage Rating: 72 V
- Rating Temperature: 75°C
Material Specifications
- Conductor: 0.57 mm Bare Copper (23 AWG) × 4 Pairs
- Insulation: HDPE Insulation
- Outer Diameter: 6.1 mm (Nominal)
- Jacket: PVC Jacket
- Jacket Hardness: 45P (90A +/- 2A, Shore)
- Construction: Two insulated conductors twisted together (4 pairs)
Compliance & Certification
- TIA/EIA 568C.2
- ISO/IEC 11801 Class E
- UL Listed
- ETL Verified
Applications
- Enterprise LAN Infrastructure
- Office & Commercial Networking
- Data Centers
- Structured Cabling Systems
- Gigabit Ethernet Installations
