• The D-Link 48-Port Cat 6 Patch Panel (NPP-C61BLK481) is designed to support high-speed networking applications in enterprise and data center environments.

• This panel is preloaded with Cat 6 ports, ensuring superior performance, reliability, and easy cable management.

• It is compatible with standard 19-inch racks and provides a structured wiring solution with reduced signal loss and interference.

Technical Specifications:

• Product Type: Loaded Patch Panel

• Total Ports: 48

• Category: Cat 6

• Connector Type: RJ45

• Mounting: Standard 19-inch rack-mountable (2U)

• Conductor Material: Phosphor Bronze with Gold Plating

• Insulation Material: Polycarbonate UL94V-0

• IDC Type: 110 and Krone Compatible

• Wiring Scheme: TIA/EIA-568A & TIA/EIA-568B

• Contact Resistance: ≤ 20mΩ

• Insulation Resistance: ≥ 500MΩ

• Performance:

• Supports data transmission speeds up to 1 Gbps

• Bandwidth up to 250 MHz

• Enhanced noise reduction and minimal signal interference

• Compliance:

• ANSI/TIA-568-C.2

• ISO/IEC 11801

• RoHS Compliant
